13T Hydraulic Rear Tilt Dump Truck With 7 Cubic Meters Dump Box

Name: 13T Hydraulic Rear Tilt Dump Truck With 7 Cubic Meters Dump Box
Brand: Zhuanzhi
Price: 21 USD

Quality 13T Hydraulic Rear Tilt Dump Truck With 7 Cubic Meters Dump Box wholesale

Brand Name : Zhuanzhi

Place of Origin : Hubei, China

Price : $21,000.00/units 1-2 units

Condition : New

Steering : Left

Horsepower : 95-110hp

Emission Standard : Euro 3

Segement : Mini truck

Market Segement : Urban construction muck transportation

Fuel Type : Diesel

Engine Capacity : < 4L

Transmission Type : Manual

Forward Shift Number : 5

Reverse Shift Number : 1

Maximum Torque(Nm) : 500-1000Nm

Dimensions (L x W x H) (mm) : 6850x2280x3100

Cargo Tank Dimension : 4200x2200x800

Cargo Tank length : ≤4.2m

Gross Vehicle Weight : 3360

Capacity (Load) : 1 - 10t

Drive Wheel : 4X2

Passengers : 2

Driver's Seat : Normal

Rear Camera : Camera

Cruise Control : Normal

ABS(Antilock Braking System) : Yes

ESC(Electronic Stability Control System) : Yes

Touch Screen : Yes

Multimedia System : Yes

Window : Automatic

Air Conditioner : Automatic

After-sales Service Provided : Video technical support, Online support, Free spare parts

Color : Customer's Requirement

Wheelbase(mm) : 3650

Total weight (kg) : 9500

Size (mm) : 6850x2280x3100

Payload(kg) : 6200

Cargo box size (mm) : 4200x2200x800

Engine power (kw) : 118

Displacement (cc) : 4257

Transmission : 8 speed, Manuel

Tire Size : 9.00-20

Contact Now

Product Description

Dongfeng 4X2 13T Hydraulic Rear Tilt Dump Truck WIth 7 Cubic Meters Dump Box

Specification

Dimension &Weight
Overall dimension	6850x2280x3100
wheelbase (mm)	3650
total weight (kg)	9500
tare weight (kg)	3360
Payload (kg)	6200
cargo box size (mm)	4200x2200x800
Engine
Engine model	YC4E160 (YUCHAI ENGINE)
Fuel type	Diesel
Engine type	Water cool, 4cylinder in-line, turbocharge ,intercooler
Engine power (kw)	118
Max torque (N.m/rpm)	600/1200-1600
Displacement(cc)	4257
Fuel consumption (L/100km)	10
Emission	III
Chassis system
transmission	8 speed, Manuel
suspension type	Leaf spring
axles capacity	Front 5T / Rear 8T
steering	Power steering
Tire	9.00-20

Factory Show

Packing and shipping

Company Introduction

Ricalt Automobile Technology (Hubei) Co., Ltdestablished on March 3, 2015, is located at No. 40 dongfeng Avenue, Maojian District, Shiyan City, Hubei Province. The truck commercial vehicle industry belt formed by relying on Dongfeng Motor Company.

Our business scope
We mainly produce all kinds of special purpose trucks as per the requests of our buyer . Including : Water truck .Fuel tank truck.Truck mounted crane .MIxer truck. Dump truck. Garbage truck .etc .etc.

Our Advantages

1.Wide range of vehicles
We have a wide range of different vehicles, including mini-truck, light truck, heavy-duty trucks, microbus, mini-bus, big-sized bus, pickup. The clients can achieve agency from us for different brands and types of vehicles with different manufacturers.

2.Customized vehicles
We could also customize the vehicles according to the demand of the end markets, technical and equipment modification as per demand.

FAQ

1: I don't want this configuration.
A: The configuration can be changed according to your needs

2: Minimum order quantity?
A: MOQ is 1 unit.

3: Shipping?
A: (Truck & trailer)
by container or RoRo/Bulk shipment. (South America, Middle East, Africa, Oceania etc.)

4:What kind of payment could be acceptable?
A: Generally we accept T/T .LC .And westunion.

5: Can you supply some quick-wear truck or semi trailer parts ?
A: Yes, we can supply truck and semi trailer parts as your request,such as oil filter, fuel filter, air filter, traction, traction pin, balance beam and semi-trailer plate spring, hanging accessories, turntable, all kinds of trailer brake pads, brake pan,bearings etc.
