EQ2070 Military Truck Cummins Engine 160HP 4x4 Off Road Truck For Army Used

  • 1
  • 2

Brand Name : Dongfeng

Model Number : EQ2070

Certification : CCC

Place of Origin : China

MOQ : 1 Unit

Payment Terms : T/T,L/C

Supply Ability : 2000 units per year

Delivery Time : 35 working days

Packaging Details : In Nude

Drive type : 4x4

Fuel type : Diesel

Engine type : 160HP

Dimension : 6500x2470x2825mm

GVW : 8510kg

Curb weight : 5800kg

Cargo box size : 3545x2294x550mm

Wheelbase : 3600mm

Transmission : 6 speed,manual

Tyre : 12.5R20

Cab : Half a row

Contact Now

EQ2070 Military Truck Cummins Engine 160HP 4x4 Off Road Truck For Army Used

EQ2070 Parameters Specifications

Description Military chassis
Drive type 4x4,LHD
Cab Flat roof,single row
Passenger 3 persons
Wheelbase 3600(mm)
Clutch Φ350mm,Single disc clutch
Gearbox 6 Speed,manual
Transfer case Mechanical, two gears
Front axle(Empty load/full load) 3425/2575
Rear axle(Empty load/full load) 3805/4905
Oil tank 145(L)
Tire 12.5R20,with one spare tire
Engine model EQB160-22,In-line six cylinder water-cooled intercooler diesel engine
Engine power 118(kW)/160(hp)
Engine brand CUMMINS
Fuel type diesel
Displacement 5900(ml)
Approach angle/departure angle 35/33(°)
Front /rear suspension 1400/1430(mm)
GVW 8710(kg)
Max load capacity 2500(kg)
Max tractive mass 2500(kg)
Max speed 91(km/h)
Min stable speed 3(km/h)
Max gradient 60%
Slope standing capacity 40%
Min ground clearance 305(mm)
Min turning radius 7.5(m)
Max vertical obstacle clearance height 550(mm)
Max trench crossing width 700(mm)
Max wading depth 1000(mm)
Max range 800(km)

EQ2070 Military Truck Cummins Engine 160HP 4x4 Off Road Truck For Army Used

Dongfeng flat-head four-wheel drive off-road vehicle EQ2070 is equipped with Cummins 160/190 horsepower engine, 1250 off-road steel wire tire, and one-and-a-half-row cab. Developed according to different customer uses and working conditions, Dongfeng four-wheel drive off-road vehicle EQ2070 has high power and high mobility advantages in desert exploration, muddy roads, mountain road transportation, factory turnover, forest crossing, mining area cargo transportation, etc., helping customers complete tasks that conventional vehicles cannot complete.
